Feature:

1. Easily change the belt.

2.Small space of machine bench for east reaches by extending the hands thus facilitating Maintenance.

3.Horizontal method is adopted for tape application, during which the carton box is stopped thus enabling smoothness of adhesion and nice appearance because of no sibe force.

4.Single way lateral movement is adopted and sliding bearing and bearing steel shaft are utilized thus making smooth movement without noise.

5. Automatic ascending and descending for change of width.

6.  Equipped with pressure switch, during sealing, pressure can automatically release and side clamp will be open.

7.  With upright tape blowing structure, tape will not be too hot for softening and bending and will not be too think for dropping thus resulting poor carton sealing.

Specification:

Model No	JT-H400
Carton Size	L300-600* W200-500 * H180-500(mm)
Table Height	Max800 ,Min 650 (mm)
Sealing Speed	400Carton/Hour
Machine Size	L2000* W1200 *H1500 (mm)
Power/Air Consumption	220V/380V , 50/60HZ / 5kg
Belt Size	60- 75mm
Net Weight	450kg
